Single Horizontal Support - Promaster - Driver or Passenger

Single horizontal support for the rear door, passenger and/or driver side, compatible with the Ram Promaster 2014+. This tubular support is designed for the installation of small trunks only. With a simple and minimalist design, this support does not compromise visibility through the rear windows of the vehicle while allowing you to add more storage for your accessories such as the BBQ, sporting goods, or others that you do not want to keep inside your living space. It is possible to attach storage baskets above the trunk. The supports are designed to follow the opening movement of the doors, thus facilitating access to the interior of the vehicle.

Designed and manufactured in Quebec.

Specifications:

• 6061 aluminum bracket.
• Fully TIG welded construction.
• Load capacity of 200 lbs, including the weight of the rack.
• Weight of bracket with fixing and hardware: 18 lbs.
• 308 stainless steel hinge bracket.
• Stainless steel mounting hardware.
• Textured black powder coat baked paint.
• Suitable for Promaster vans, with or without rear windows.

• 2 x 10 inch support arms with 1.5 inch diameter tube mount are included with each bracket.

Warnings:

• Do not add additional items such as fuel cans or similar to the exterior side of the box. This will void your warranty as it significantly increases the leverage of the weight when closing the door.
• When the carrier is fully loaded, the door should be closed gently and not slammed.
• Overloading boxes or accessories may damage doors and hinges, voiding your warranty.
• Can activate the reversing sensors when reversing (this varies by van).

Assembly :

The brackets install using the existing hardware on the rear doors, without the need to drill new holes. A set of two 10-inch support arms with 1.5-inch diameter tube mounts are included with each bracket. Installation is offered at $150 at our establishment.
