Bike rack support arm for tubular rack

The Horizontal Bike Rack Support Arms are made of aluminum and are sold in a set of 2. They are designed to attach to the side tubes of the Phlö System Full Door Tubular Racks for the right passenger side (cannot be installed on the left driver side door as the bike rack will prevent the rear doors from opening). Equipped with a 4-bolt stainless steel fastener, they easily attach to the Phlö System tubular racks with a diameter of 1.5 inches. These arms are 22 inches long and allow the installation of horizontal bike racks such as the Rack OneUp flush mount, Thule and other horizontal racks.

Specifications:

• Material: 3/16 inch thick 5052 aluminum.
• Maximum capacity of 80 pounds per arm set.
• Load capacity of 200 pounds, including the weight of the stand.
• Weight: () pounds for 2 arms.
• Stainless steel mounting hardware included.
• Textured black powder coat baked paint.
• Specific design for the Phlö tubular support system.
• Designed and manufactured in Quebec.

Warnings:

• When the carrier is fully loaded, the door should close gently and not slam shut.
• Overloading boxes or accessories may damage doors and hinges, voiding your warranty.
